Chaibuxi Bridge

From HighestBridges.com
Jump to navigationJump to search

Chaibuxi Bridge
柴埠溪特大桥
Yuyangguanzhen, Hubei, China
951 feet high / 290 meters high
1,575 foot span / 480 meter span
2024

Chaibuxi Render.jpg


The highest cable stayed bridge in Hubei Province, the Chaibuxi Bridge crosses a deep section of the Chaibuxi River just 3 kilometers west of Yuyangguan City along the G59 Yilai Expressway between Yibin and Laifeng.

Located at kilometer 14, the 1,384 meter long structure has a main span configuration of 66+146+480+146+80 meters supported by towers 213 and 167 meters tall. Long approach viaducts on both sides are supported by many 30 meter approach spans. The huge deck is 44.5m wide with a 4 lane expressway +2 local road lanes and a walkway.

Just a kilometer to the south is the Hanyanghe arch bridge completed in 2014 along local route S325.

http://www.highestbridges.com/wiki/index.php?title=Hanyanghe_Bridge



Chaibuxi Bridge Elevation







Image by Eric Sakowski / HighestBridges.com



Image by Eric Sakowski / HighestBridges.com



Image by Eric Sakowski / HighestBridges.com



Image by Eric Sakowski / HighestBridges.com



Image by Eric Sakowski / HighestBridges.com



Image by Eric Sakowski / HighestBridges.com



Image by Eric Sakowski / HighestBridges.com



Image by Eric Sakowski / HighestBridges.com



Image by Eric Sakowski / HighestBridges.com



Image by Eric Sakowski / HighestBridges.com





















Chaibuxi Bridge satellite image.





Chaibuxi Bridge location map.
