Revision as of 02:53, 8 February 2017
Msikaba Bridge
Tahle, Eastern Cape, South Africa
636 feet high / 194 meters high
1,903 foot span / 580 meter span
2022
The beautiful Msikaba Bridge is scheduled to become the longest span crossing ever constructed on the African Continent with a tower to tower distance of 580 meters. This will surpass the Matadi suspension bridge across the Congo River which opened in 1983 with a span of 520 meters. The new cable stayed bridge will also become the second highest bridge in Africa with a deck 194 meters high. This drop is exceeded only by the 223 meter high Mtentu Bridge also located on the new N2 tollway bypass.
The Msikaba and Mtentu Bridges are part of an improvement to the older N2 Wild Coast Toll Road that will be 85 kilometers shorter and 3 hours faster. Designed by DISSING+WEITLING, the concrete structure will have a deck 22.8 meters wide with walkways on both edges.
The Msikaba Bridge will eventually have walkways added to both edges of the deck.
Msikaba Bridge location map.
