Kokonoe "Yume" Otsurihashi Footbridge
Kokonoe, Oita, Japan
568 feet high / 173 meters high
1,280 foot span / 390 meter span


The Kokonoe "Yume" Otsurihashi suspension footbridge was upon its completion the longest and highest of its type in the world. Opened in 2006, the main span of 1,280 feet (390 mtrs) surpassed the previous record holder, the Ryujin footbridge - also in Japan - which has a span of 1,230 feet (375 mtrs). Kokonoe was also Japan’s highest bridge at 568 ft. (173 mtrs) - a record it retained for 4 years until 2010 when the Hiroshima Airport arch bridge opened. Neither bridge however, is as long as the catenary Baglung Parbat Foobridge in Nepal with a span of 567 meters and Japan's own Mishima Skywalk near Mount Fuji opened with a main span of 400 meters. Switzerland’s Niouc was once the highest footbridge in the world but is also a catenary suspension bridge with no towers. Many do not consider catenary bridges to be true suspension bridges since they have uneven, sloping decks that are often unstable.

Of course the Japanese are no strangers to high and long footbridges. Prior to Ryujin and Kokonoe, one of the country’s longest suspension footbridges was the 1984-built Teruha bridge in Aya with a tower to tower distance of 820 feet (250 mtrs). At the time Aya also held Japan’s bridge height record at 466 feet (142 mtrs). Other high footbridges in Japan include the Ueno Skybridge some 295 feet (90 mtrs) above a forested valley and the Tanise suspension bridge 177 feet (54 mtrs) high with a length of 974 feet (297 mtrs). Constructed in Totsukawa, Nara prefecture in 1954, Tanise is one of Japan’s oldest suspension footbridges and is unusual for having two separate sets of main support cables.

The name "Yume" means dreams - a representation of the people of Kokonoe and their desire to bring the people of the region together in one harmonious exchange of ideals and culture. Or something to that effect. A more simple reason to have built the bridge is for the outstanding views it offers of the Naruko-gawa gorge and its towering cliffs and waterfalls. Like any good footbridge of great height, Kokonoe has a narrow 5 foot (1.5 mtr) wide walkway that will induce many with a feeling of vertigo. Some will find this nerve racking while others will find it euphoric.

Although it no longer exists, the highest and longest tower supported suspension footbridge built at the time of its completion was upstream of the massive Glen Canyon Dam over the Colorado River in the U.S. State of Arizona from 1958 to 1964 to aid worker’s during the dam’s construction. It had a height of 640 feet (195 mtrs) and a span of 1,280 feet. An accurate conversion puts the 390 meter long Kokonoe bridge span at 1,279.5276 feet - about 6 inches short of the Arizona bridge!


Kokonoe "Yume" Otsurihashi Footbridge Elevation

九重“夢”大つり橋は歩行者専用の橋で、このタイプの橋の中では世界一長く高い橋です。2006年にオープンした長さ390mのこの橋は、それまで記録を保持していた長さ375mの竜神大吊橋(歩行者専用)を超えるものです。175mの高さを持つ九重“夢”大つり橋は、2010年に広島空港大橋がオープンするまで、四年間日本一高い橋として記録を保持していました。しかし、どちらの橋も、マレーシア、セランゴルのスンウェイラグーン・テーマパーク(Sunway Lagoon Theme Park in Selangor, Malaysia)にある全長428mのカテナリー型(垂れている)つり橋ほど長くはありません。スイスのニオク(Niouc)は現在世界で最も高い歩行者用つり橋 ですが、タワーのないカテナリー 型つり橋です。カテナリー 型つり橋には、しばしば平らでなく不安定に傾斜するデッキがあるため多くの人はこの橋を真のつり橋として認めていません。




World's 40 Longest Footbridge Spans

1. Sky Bridge 721, Czech Republic - 721 meters

2. Skywalk Willingen, Germany – 665 meters

3. Yundingfeidu Glass Footbridge, China – 615 meters

4. Tibetan Footbridge of Canillo, Andorra - 603 meters

5. Haizhaigou UFO Glass Footbridge, China - 600 meters

6. Castelsaraceno Footbridge, Italy - 580 meters

7. Gandaki Golden/Baglung Parbat, Nepal - 567 meters

8. 516 Arouca, Portugal - 516 meters

9. Wanjiazhai Dam, China - 500 meters

10. Charles Kunonen, Switzerland – 494 meters

11. Kushma Bungy, Nepal - (490) meters

12. Huangchuansanxia Glass, China - 460 meters

13. Rappbode Dam, Germany - 458 meters

14. Blackforestline of Todtnau, Germany - 450 meters

15. Tianyundu Glass Footbridge, China - (450) meters

16. Daqingshan Glass Footbridge, China - 450 meters

17. Longguwan Glass Footbridge, China - (445) meters

18. Hongyagu Glass, China - 445 meters

19. Sochi Skybridge, Russia – 439 meters

20. Zhangjiajie Grand Canyon Glass, China – 430 meters

21. Yinzuotianmeng, China – 420 meters

22. Longguashan Footbridge, China – (410) meters

23. Chikhaldara Glass Skywalk, India - 407 meters

24. Ulleong Sogeumsan, South Korea - 404 meters

25. Highline 179, Austria – 402 meters

26. Mishima Grand, Japan – 400 meters

27. Kokonoe Otsurihashi, Japan - 390 meters

28. Nanjiang Gorge Glass Footbridge, China - (385 meters)

29. Jorullo ATV Bridge, Mexico - 380 meters

30. Ryujin, Japan - 375 meters

31. Skywalk Sattel, Switzerland - (374 meters)

32. Yunjian Glass Footbridge, China - (365 meters)

33. Bega-Banduk, Nepal - 365 meters

34. Geierlay, Germany – 360 meters

35. Kushma-Mudhikuwa, Nepal - 359 meters

36. Baiheshanzhuang Footbridge, China - 358 meters

37. Qingrengu Glass Footbridge, China - (355 meters)

38. Bailihuang Glass Footbridge, China - 350 meters

39. Triveni Garas, Nepal - 350 meters

40. Bunwajorghat, Nepal - 350 meters

41. Shuiyuan Footbridge, China - 342 meters




















Kokonoe "Yume" Otsurihashi Footbridge satellite image.



Kokonoe "Yume" Otsurihashi Footbridge location map.
